    Orbit® 3 Digital Gauging and Positioning Network



    Introducing the Solartron Orbit® Network: a fully formed digital measurement system that makes it simple and easy to inter-connect high accuracy Solartron instruments, and other sensors to your computer, network, or PLC.



    Calibrated System

    Each Solartron probe or instrument is available with a digital module at the end of the cable. Inside the module is a chip that digitizes the analogue signal from the probe. The probe is actually calibrated and linearized at the Solartron factory, with a guaranteed accuracy of 0.05% of range or 0.2 microns, whichever is greater, 0.15 micron repeatability, and 0.01 micron resolution. You can then master the probe anywhere over its measurement range, and attain the same accuracy from that master point. Solartron also offers a variety of calibrated non-contact Laser sensors available.

    Orbit® 3



    Network up to 150 Channels

    You then connect the Solartron sensor to almost any output device via Orbit®. The Orbit® network, now in its 3rd generation, Orbit® 3, is based on a proven and rugged RS485 multi-drop network running at 1.5m Baud. To build one, you stack any number of digital modules together via use of “T-connectors.”





    Connect to other Sensors

    The Orbit® 3 Network will also connect to 3rd party sensors via interface modules. These include:

    Analogue Interface Module (AIM): Connect to any sensor                 with a DC or 4-20mA output.

    Encoder Input Module, (EIM): Connects with any rotary                     encoder or other device with a TTL output. With    these                   connections, all readings can be sent to a PLC or    PC                   seamlessly.

    Digimatic Input Module: Connects to any Mitutoyo gauge

    Digital Input/Output Module: An eight-pin module that acts as         an I/O interface to a PLC.



    (Orbit3)







    Interface to PLC, PC, or Readout

    At the end of the module stack, you then connect an Interface module, available with a variety of outputs including USB, RS232 and Ethernet. Each connects with up to 150 modules! With the USB, you also attain dynamic speeds of up to 4000 readings per second, per module.

    Via the interface module, you can then output any module reading to a computer, PLC, or network. For PC’s, Solartron offers free software drivers, which provide sample programs and coding to communicate with the probes via SPC program, Microsoft Excel, or other data tracking software. The drivers are Windows 7, 64-bit and XP compatible.

    Solartron also offers a variety of Digital Readouts, including 1, 2, 16, and 31 channels.

    A Solartron Power Supply Interface Module is also required for a Orbit® 3 network stack, and will power up to 31 modules at once. They are available with both DC and AC inputs.

    With all its capabilities, the Solartron Orbit® 3 Network is the best solution for your gauging and measurement needs!
