CSH05FL-CRm1,4

Brand : Micro-Epsilon
Type : capaNCDT(Sensor)
Model : CSH05FL-CRm1,4
Measuring range : 0.5 mm
Active measuring area : Ø4.1 mm
Min. target size (flat) : Ø7 mm
Linearity : ≤ ±0.09 µm
Resolution : 10 nm
Temperature stability :-6 nm/K




LLT 30x2-200

Brand : Micro-Epsilon
Type : scanCONTROL 30x2
Model : LLT 30x2-200
z-axis
Measuring range
        Start : 200 mm
          Mid : 310 mm
          End : 420 mm
      Height : 220 mm
Extended measuring range
        Start : 160 mm
          End : 460 mm
Max. deviation of a single point
   Red Laser : ±0.12 %
   Blue Laser : -
Line linearity : 30 µm
x-axis
Measuring range
        Start : 130 mm
          Mid : 200 mm
          End : 270 mm
Extended measuring range
        Start : 100 mm
          End : 290 mm
Resolution : 1024 points/profile
Profile frequency  : up to 5,000 Hz
Interfaces
  Ethernet GigE Vison
     Output of measurement values
     Sensor control
     Profile data transmission
  Digital inputs
     Mode switching
     Encoder (counter)
     Trigger
  RS422 (half-duplex)
      Output of measurement values
      Sensor control
      Trigger
      Synchronization
Output of measurement values
  Ethernet (UDP / Modbus TCP)
  RS422 (ASCII / Modbus RTU)
  analog ; switch signal
  PROFINET ; EtherCAT ; EtherNet/IP
Protection class :  IP67 (when connected)
Supply voltage : 11 … 30 VDC , Power over Ethernet                              (PoE)

ODC1200 (axial model)

Brand : Micro-Epsilon
Type : optoCONTROL 1200/1201
Model : ODC1200 (axial model)
Measuring ranges : 5 mm
Frequency response : 100 kHz (-3db)
Linearity : ≤ 2 % FSO
Resolution (dynamic) typ. : 25 µm
Protection class : IP67
Supply voltage : 12-32 VDC
Distance light source - receiver (free space) : min. 20 mm to max. 5 m
Light source : semiconductor laser < 0.39 mW, 670 nm (red, laser class 1)
Analog output : 0 ... 10 VDC (adjustable gain)
Switching output : PNP dark switching and NPN bright switching (max. switching frequency 60 kHz)                                    adjustable signal threshold

CSH1FL-CRm1,4

Brand : Micro-Epsilon
Type : capaNCDT(Sensor)
Model : CSH1FL-CRm1,4
Measuring range : 1 mm
Active measuring area : Ø5.7 mm
Min. target size (flat) : Ø11 mm
Linearity : ≤ ±0.2 µm
Resolution : 20 nm
Temperature stability :-12 nm/K




LLT 30x0-25

Brand : Micro-Epsilon
Type : scanCONTROL 30x0
Model : LLT 30x0-25
z-axis
Measuring range
        Start : 77.5 mm
          Mid : 85 mm
          End : 92.5 mm
      Height : 15 mm
Extended measuring range
        Start : -
          End : -
Max. deviation of a single point
   Red Laser : ±0.08 %
   Blue Laser : ±0.06 %
Line linearity : 1.5 µm
x-axis
Measuring range
        Start : 23 mm
          Mid : 25 mm
          End : 26.8 mm
Extended measuring range
        Start : -
          End : -
Resolution : 2048 points/profile
Profile frequency  : up to 10,000 Hz
Interfaces
  Ethernet GigE Vison
     Output of measurement values
     Sensor control
     Profile data transmission
  Digital inputs
     Mode switching
     Encoder (counter)
     Trigger
  RS422 (half-duplex)
      Output of measurement values
      Sensor control
      Trigger
      Synchronization
Output of measurement values
  Ethernet (UDP / Modbus TCP)
  RS422 (ASCII / Modbus RTU)
  analog ; switch signal
  PROFINET ; EtherCAT ; EtherNet/IP
Protection class :  IP67 (when connected)
Supply voltage : 11 … 30 VDC , Power over Ethernet                              (PoE)

ODC1200 (axial model)

Brand : Micro-Epsilon
Type : optoCONTROL 1200/1201
Model : ODC1200 (axial model)
Measuring ranges : 10 mm
Frequency response : 100 kHz (-3db)
Linearity : ≤ 3.5 % FSO
Resolution (dynamic) typ. : 50 µm
Protection class : IP67
Supply voltage : 12-32 VDC
Distance light source - receiver (free space) : min. 20 mm to max. 5 m
Light source : semiconductor laser < 0.39 mW, 670 nm (red, laser class 1)
Analog output : 0 ... 10 VDC (adjustable gain)
Switching output : PNP dark switching and NPN bright switching (max. switching frequency 60 kHz)                                    adjustable signal threshold

CSH1,2FL-CRm1,4

Brand : Micro-Epsilon
Type : capaNCDT(Sensor)
Model : CSH1,2FL-CRm1,4
Measuring range : 1.2 mm
Active measuring area : Ø6.3 mm
Min. target size (flat) : Ø11 mm
Linearity : 0.84 µm
Resolution : 24 nm
Temperature stability :-14.4 nm/K




LLT 30x0-50

Brand : Micro-Epsilon
Type : scanCONTROL 30x0
Model : LLT 30x0-50
z-axis
Measuring range
        Start : 105 mm
          Mid : 125 mm
          End : 145 mm
      Height : 40 mm
Extended measuring range
        Start : -
          End : -
Max. deviation of a single point
   Red Laser : ±0.08 %
   Blue Laser : ±0.06 %
Line linearity : 3 µm
x-axis
Measuring range
        Start : 43.3 mm
          Mid : 50 mm
          End : 56.5 mm
Extended measuring range
        Start : -
          End : -
Resolution : 2048 points/profile
Profile frequency  : up to 10,000 Hz
Interfaces
  Ethernet GigE Vison
     Output of measurement values
     Sensor control
     Profile data transmission
  Digital inputs
     Mode switching
     Encoder (counter)
     Trigger
  RS422 (half-duplex)
      Output of measurement values
      Sensor control
      Trigger
      Synchronization
Output of measurement values
  Ethernet (UDP / Modbus TCP)
  RS422 (ASCII / Modbus RTU)
  analog ; switch signal
  PROFINET ; EtherCAT ; EtherNet/IP
Protection class :  IP67 (when connected)
Supply voltage : 11 … 30 VDC , Power over Ethernet                              (PoE)

ODC1200 (axial model)

Brand : Micro-Epsilon
Type : optoCONTROL 1200/1201
Model : ODC1200 (axial model)
Measuring ranges : 16 mm
Frequency response : 100 kHz (-3db)
Linearity : ≤ 3.5 % FSO
Resolution (dynamic) typ. : 80 µm
Protection class : IP67
Supply voltage : 12-32 VDC
Distance light source - receiver (free space) : min. 20 mm to max. 5 m
Light source : semiconductor laser < 0.39 mW, 670 nm (red, laser class 1)
Analog output : 0 ... 10 VDC (adjustable gain)
Switching output : PNP dark switching and NPN bright switching (max. switching frequency 60 kHz)                                    adjustable signal threshold

CSH2FL-CRm1,4

Brand : Micro-Epsilon
Type : capaNCDT(Sensor)
Model : CSH2FL-CRm1,4
Measuring range : 2 mm
Active measuring area : Ø8.1 mm
Min. target size (flat) : Ø17 mm
Linearity : 0.32 µm
Resolution : 40 nm
Temperature stability :-24 nm/K
