MCi Machine Control: the Unidrive M700 with MCi module allows ultimate performance through advanced machine control



  • MCi adds a powerful second onboard micro processor for high performance IEC 61131-3 based machine control. MCi200 and MCi210 deliver our most powerful advanced onboard machine control, encompassing a 1.5 axis motion controller, real-time drive-to-drive synchronization, high speed digital I/O and integrated safety features, greatly reducing the need for expensive external components. Comprehensive application programs are intuitively written using Machine Control Studio(based on the industry standard CODESYS environment) to build highly flexible and productive machines quickly.

Features Specifications Downloads

Optimize machine productivity with powerful networked onboard automation and motion control

MCi machine controller is configured using industry standard IEC 61131-3 programming languages within the CODESYS         programming environment.

Additional MCi modules can be added for multi-processing, giving even greater machine control capability.

Access to a comprehensive library of drive and machine control function blocks and applications allows the user to achieve       performance without effort.



Open Ethernet communications with IEEE 1588 V2 network synchronization

IEEE 1588 V2 hardware implementation with sub microsecond synchronization accuracy.

Integrated dual port switches for easy connectivity.

Integration with external I/O and control of non-intelligent drives.
