The SM-EZ Motion module and Power Tools Pro software provide a user friendly environment for motion programming. The EZ-Motion approach is ideal for applications that are low volume and low engineering time. Features include:

  • Simple drag and drop programming allows the user to create programs “out of the box” without having to write any code
  • Programming can be completed in 5 steps, with the software guiding the user through drive configuration, I/O configurations and programming steps
  • Familiar Windows™ based environment with simple data entry
    •      “Fill-in-the-blank” values
    •       “Point and click” radio buttons
    •      “Scrolling” menu selections
    •      “Drag and drop” parameters
  • The module has four digital inputs and two digital outputs for high-speed I/O operations
