Control Techniques’ incremental encoder input option module supports the following encoder inputs:

  • Closed-loop vector motor feedback
  • Quadrature encoder input
  • Marker pulse
  • Incremental encoders with frequency and direction signals
  • Incremental encoders with forward and reverse signals
  • Maximum input frequency 500kHz
  • 5V, 8V and 15V signals

Specifications Downloads

Option Module User Guides
Title Issue File Type Size Lang
SM-Encoder Plus/Encoder Output Plus User Guide 4 pdf 868 KB EN Download
SM-Universal Encoder Plus User Guide 6 pdf 3.00 MB EN Download

Visio Drawings
Title Issue File Type Size Lang
Control Techniques Visio Shapes   zip 28 MB EN Download
Instructions for using Control Techniques Visio Shapes   pdf 272 KB EN Download


Further information



Click here to download the SM-Options brochure






Please register here in order to access the download page.
