High Precision True Color Controller – colorSENSOR CFO200

The CFO200 is designed for high performance, relative color measurements. With a measuring rate of 30kHz, even dynamic high speed production processes can be monitored reliably. High repeatability enables the reliable detection of even the slightest color differences. The color memory offers teach-in of up to 320 colors in 254 color groups.



 Characteristics

  •  Measurement speed: max. 30 kHz
  •  Color memory: 320 colors in 254 color groups
  •  Color distance: ΔE ≤ 0.6
  •  Repeatability ΔE ≤ 0.3
  •  8 switching outputs
  •  Intuitive setup via web interface

Data sheet colorSENSOR CFO100/200
