Recommended Substitute
|
|
Model in use |
Comments |
|
AST3301-T1-D24 |
ST3000 Series
5.7" TFT color LCD
|
|
Recommended Substitutes |
Comments |
Details |
|
PFXGP4301TADW |
GP4000 Series
panel cut-out size same
|
 |
|
PFXGP4301TAD |
GP4000M Series
panel cut-out size same
SD card available
|
|
|
|
|
[ Migration ] Replacing ST-3301T/S/B with GP-4301TW
Specification Comparison
|
|
ST-3301T/S/B |
GP-4301TW |
|
|
|
|
Model No. |
AST3301-S1-D24
AST3301-T1-D24
AST3301-B1-D24 |
PFXGP4301TADW |
|
Display Type |
ST-3301T : TFT Color LCD
ST-3301S : STN Color LCD
ST-3301B : Monochrome blue mode LCD |
TFT Color LCD |
|
Display Colors |
ST-3301T : 256 colors (without blink)/
64 colors (with blink)
ST-3301S : 256 colors (without blink)/
64 colors (with blink)
ST-3301B : Monochrome, 8 levels |
UP!
65,536 colors (without blink)/
16,384 colors (with blink) |
|
Display Resolution |
QVGA(320×240 pixels) |
|
Panel Cutout Dimensions (mm) |
W156×H123.5mm |
|
External Dimensions (mm) |
W167.5×H135×D59.5mm |
W169.5×H137×D59.5mm |
|
Touch Panel Type |
Resistive film (Analog) |
|
Memory (Application) |
6MB |
UP!
8MB |
|
Memory (SRAM) |
320KB |
128KB*1 |
|
Backup Battery |
Secondary Battery
(Rechargeable Lithium battery) |
|
Serial I/F (COM1) |
D-Sub9 pin (plug)
RS-232C |
|
Serial I/F (COM2) |
D-Sub9 pin (plug)
RS-422/485 |
|
Ethernet I/F |
- |
NEW!
10BASE-T/100BASE-TX |
|
USB Type A |
✔ |
✔*1 |
|
USB Type mini B |
- |
*1 There are some restrictions regarding replacement with recommended substitutes.
|
|
|
[ Migration ] Replacing ST-3301T with GP-4301T
Specification Comparison
|
|
ST-3301T |
GP-4301T |
|
|
|
|
Model No. |
AST3301-T1-D24 |
PFXGP4301TAD |
|
Display Type |
TFT Color LCD |
|
Display Colors |
256 colors (without blink)/
64 colors (with blink) |
UP!
65,536 colors (without blink)/
16,384 colors (with blink) |
|
Display Resolution |
QVGA(320×240 pixels) |
|
Panel Cutout Dimensions (mm) |
W156×H123.5mm |
|
External Dimensions (mm) |
W167.5×H135×D59.5mm |
W169.5×H137×D59.5mm |
|
Touch Panel Type |
Resistive film (Analog) |
|
Memory (Application) |
6MB |
UP!
16MB |
|
Memory (SRAM) |
320KB |
|
Backup Battery |
Secondary Battery
(Rechargeable Lithium battery) |
NEW!
Primary Battery
(Replaceable Lithium battery)*1 |
|
Serial I/F (COM1) |
D-Sub9 pin (plug)
RS-232C |
|
Serial I/F (COM2) |
D-Sub9 pin (plug)
RS-422/485 |
|
Ethernet I/F |
- |
NEW!
10BASE-T/100BASE-TX |
|
SD Card I/F |
- |
NEW!
✔ *1 |
|
USB Type A |
✔ |
NEW!
✔ |
|
USB Type mini B |
- |
*1 There are some restrictions regarding replacement with recommended substitutes.
|
|
|
|
|
Recommended Substitute
|
|
Model in use |
Comments |
|
AST3301W-B1-D24 |
ST3000 Series
Blue mode Monochrome LCD
|
|
Recommended Substitutes |
Comments |
Details |
|
PFXGM4301TAD |
GP4000M Series
modular type(22mm circular hole)
panel cut-out size difference
|
Please contact Scigate (+65 6561 0488) or e-mail us at sales@scigate.com.sg |
|
|
|
|
|
Recommended Substitute
|
|
Model in use |
Comments |
|
AST3301W-S1-D24 |
ST3000 Series
STN color LCD
|
|
Recommended Substitutes |
Comments |
Details |
|
PFXGM4301TAD |
GP4000M Series
modular type(22mm circular hole)
panel cut-out size difference
|
Please contact Scigate (+65 6561 0488) or e-mail us at sales@scigate.com.sg |
|
|
|
|
|
Recommended Substitute
|
|
Model in use |
Comments |
|
AST3302-B1-D24 |
ST3000 Series
3.5" Monochrome LCD
Amber/Red LCD
|
|
Recommended Substitutes |
Comments |
Details |
|
PFXGP4303TAD |
GP4000 Series
panel cut-out size same
TFT color LCD
(Available Monochrome mode)
|
|
|
|
|
[ Migration ] Replacing ST-3302B with GP-4303T
Specification Comparison
|
|
ST-3302B |
GP-4303T |
|
|
|
|
Model No. |
AST3302-B1-D24 |
PFXGP4303TAD |
|
Display Type |
Monochrome
Blue Mode LCD |
UP!
TFT Color LCD |
|
Display Colors |
Monochrome, 8 levels |
UP!
65,536 colors (without blink)/
16,384 colors (with blink) |
|
Display Resolution |
QVGA(320×240 pixels) |
|
Panel Cutout Dimensions (mm) |
W156×H123.5mm |
|
External Dimensions (mm) |
W167.5×H135×D59.5mm |
NEW!
W169.5×H137×D59.5mm |
|
Touch Panel Type |
Resistive film (Analog) |
|
Memory (Application) |
6MB |
UP!
16MB |
|
Memory (SRAM) |
320KB |
|
Backup Battery |
Secondary Battery
(Rechargeable Lithium battery) |
Primary Battery
(Rechargeable Lithium battery)*1 |
|
Serial I/F (COM1) |
D-Sub9 pin (plug)
RS-232C |
|
Serial I/F (COM2) |
D-Sub9 pin (socket)
RS-485(for MPI only) |
|
Ethernet I/F |
- |
NEW!
10BASE-T/100BASE-TX |
|
SD Card I/F |
- |
NEW!
✔ |
|
USB Type A |
✔ |
NEW!
✔ *1 |
|
USB Type mini B |
- |
*1 There are some restrictions regarding replacement with recommended substitutes.
|
|
|
|
|
Recommended Substitute
|
|
Model in use |
Comments |
|
AST3301-S1-D24 |
ST3000 Series
5.7" STN color LCD
|
|
Recommended Substitutes |
Comments |
Details |
|
PFXGP4301TAD |
GP4000M Series
modular type(22mm circular hole)
panel cut-out size difference
|
|
|
PFXGP4301TADW |
GP4000 Series
panel cut-out size same
SD card not available |
|
|
|
|
[ Migration ] Replacing ST-3301S/B with GP-4301TM
Specification Comparison
|
|
ST-3301S/ST-3301B |
GP-4301TM |
|
|
The panel cutout of GP-4301TM(link is external)is a 22-mm circular hole.
If prefer to the standard type, please refer to
replacement guidebook GP-4301TW(link is external).
|
|
Model No. |
ST-3301S: AST3301-S1-D24
ST-3301B: AST3301-B1-D24
|
PFXGM4301TAD |
|
Display Type |
ST-3301S: STN Color LCD
ST-3301B: Monochrome blue mode LCD |
TFT Color LCD |
|
Display Colors |
ST-3301S: 256 colors (without blink)
64 colors (with blink)
ST-3301B: Monochrome, 8 levels |
65,536 colors (without blink)*1
|
|
Display Resolution |
QVGA(320×240 pixels) |
|
Panel Cutout Dimensions (mm) |
W156×H123.5mm |
NEW!φ22mm *1 |
|
External Dimensions (mm) |
W167.5×H135×D59.5mm |
NEW! W163×H129.4×D56.5mm
* The rear module is included.*1 |
|
Touch Panel Type |
Resistive film (Analog) |
|
Memory (Application) |
6MB |
UP!
8MB |
|
Memory (SRAM) |
320KB |
128KB *1 |
|
Backup Battery |
Secondary Battery
(Rechargeable Lithium battery) |
- *1 |
|
Serial I/F (COM1) |
D-Sub9 pin (plug)
RS-232C |
D-Sub9 pin (plug)
RS-232C/422/485 |
|
Serial I/F (COM2) |
D-Sub9 pin (plug)
RS-422/485 |
- *1 |
|
Ethernet I/F |
- |
NEW!
10BASE-T/100BASE-TX |
|
Printer I/F |
USB |
- *1 |
|
USB Host I/F |
✔*1 |
*1 There are some restrictions regarding replacement with recommended substitutes.
|
|
|
[ Migration ] Replacing ST-3301T/S/B with GP-4301TW
Specification Comparison
|
|
ST-3301T/S/B |
GP-4301TW |
|
|
|
|
Model No. |
AST3301-S1-D24
AST3301-T1-D24
AST3301-B1-D24 |
PFXGP4301TADW |
|
Display Type |
ST-3301T : TFT Color LCD
ST-3301S : STN Color LCD
ST-3301B : Monochrome blue mode LCD |
TFT Color LCD |
|
Display Colors |
ST-3301T : 256 colors (without blink)/
64 colors (with blink)
ST-3301S : 256 colors (without blink)/
64 colors (with blink)
ST-3301B : Monochrome, 8 levels |
UP!
65,536 colors (without blink)/
16,384 colors (with blink) |
|
Display Resolution |
QVGA(320×240 pixels) |
|
Panel Cutout Dimensions (mm) |
W156×H123.5mm |
|
External Dimensions (mm) |
W167.5×H135×D59.5mm |
W169.5×H137×D59.5mm |
|
Touch Panel Type |
Resistive film (Analog) |
|
Memory (Application) |
6MB |
UP!
8MB |
|
Memory (SRAM) |
320KB |
128KB*1 |
|
Backup Battery |
Secondary Battery
(Rechargeable Lithium battery) |
|
Serial I/F (COM1) |
D-Sub9 pin (plug)
RS-232C |
|
Serial I/F (COM2) |
D-Sub9 pin (plug)
RS-422/485 |
|
Ethernet I/F |
- |
NEW!
10BASE-T/100BASE-TX |
|
USB Type A |
✔ |
✔*1 |
*1 There are some restrictions regarding replacement with recommended substitutes.
|
|
|
|
|
|
