C3HE
|
|
Brand : Kari
Media : Liquids
Application : Discharging-pump control+isolated high level alarm
Switching element : microswitch
Voltage : 6..250V AC
Max. current : 6A res, 3A ind.
Max.DC power : 75 VA
Range of adjust. : 200..1200 mm
|
Cable length : 5m (other length supplied to order)
Dimeter of sensor : 99 mm
Float casing length : 140 mm
Float material : PP
Max. operating temperature : 55°C (70°C supplied to order)
Pressure rating : 200 kPa
Water-tightness : IP67
|
|
C3LE
|
|
Brand : Kari
Media : Liquids
Application : Charging-pump control+isolated low level alarm
Switching element : microswitch
Voltage : 6..250V AC
Max. current : 6A res, 3A ind.
Max.DC power : 75 VA
Range of adjust. : 200..1200 mm
|
Cable length : 5m (other length supplied to order)
Dimeter of sensor : 99 mm
Float casing length : 140 mm
Float material : PP
Max. operating temperature : 55°C (70°C supplied to order)
Pressure rating : 200 kPa
Water-tightness : IP67
|
|
M1C
|
|
Brand : Kari
Media : Liquids
Application : Use as change-over switch
Switching element : microswitch
Voltage : 6..250V AC
Max. current : 6A res, 3A ind.
Mav.DC power : 75 VA
|
Cable length : 5m (other length supplied to order)
Dimeter of sensor : 76 mm
Float casing length : 130 mm
Float material : PP
Max. operating temperature : 55°C (70°C supplied to order)
Pressure rating : 200 kPa
Water-tightness : IP67
|
|
M1H
|
|
Brand : Kari
Media : Liquids
Application : High level alarm
Switching element : microswitch
Voltage : 6..250V AC
Max. current : 6A res, 3A ind.
Max.DC power : 75 VA
|
Cable length : 5m (other length supplied to order)
Dimeter of sensor : 76 mm
Float casing length : 130 mm
Float material : PP
Max. operating temperature : 55°C (70°C supplied to order)
Pressure rating : 200 kPa
Water-tightness : IP67
|
|
M1L
|
|
Brand : Kari
Media : Liquids
Application : Use as low level alarm device,
Switching element : microswitch
Voltage : 6..250V AC
Max. current : 6A res, 3A ind.
Max.DC power : 75 VA
|
Cable length : 5m (other length supplied to order)
Dimeter of sensor : 76 mm
Float casing length : 130 mm
Float material : PP
Max. operating temperature : 55°C (70°C supplied to order)
Pressure rating : 200 kPa
Water-tightness : IP67
|
|
M2H
|
|
Brand : Kari
Media : Liquids
Application : Discharging-pump control or prevention of pump operation when no liquid is present
Switching element : microswitch
Voltage : 6..250V AC
Max. current : 6A res, 3A ind.
Max.DC power : 75 VA
|
Cable length : 5m (other length supplied to order)
Dimeter of sensor : 76 mm
Float casing length : 130 mm
Float material : PP
Max. operating temperature : 55°C (70°C supplied to order)
Pressure rating : 200 kPa
Water-tightness : IP67
|
|
M2L
|
|
Brand : Kari
Media : Liquids
Application : Charging-pump control
Switching element : microswitch
Voltage : 6..250V AC
Max. current : 6A res, 3A ind.
Max.DC power : 75 VA
Range of adjust. : 200..1200 mm
|
Cable length : 5m (other length supplied to order)
Dimeter of sensor : 76 mm
Float casing length : 130 mm
Float material : PP
Max. operating temperature : 55°C (70°C supplied to order)
Pressure rating : 200 kPa
Water-tightness : IP67
|
|
