NNL-15B
|
|
Brand : Kansai
Media : Powder, Granules
Model : NNL-15B (Withstand load type)
Type : Reversible paddle type
Appliation : Suitable for powder not much sticking to the tank wall. Longer lasting & highly stable.
Function : Lower limit detection of a large tank. Level switch
Power : 100-110VAC or 200-220VAC 50/60Hz
Rate of rotation : 1 rpm/50Hz
|
Power consumption : 4W
Detection torque : 1470-1764 N.m x 10e-4
Mounting : Standard flange type. Level switch of withstand load type, mounted in a lower part of silo.
Allowable temperature : Below 50°C (in a tank). Both heat resistant & protective tube extension type can be manufactured.
Allowable pressure : 19.6 kPa
Enclosure rating : IP55
|
|
NNL-8DA
|
|
Brand : Kansai
Media : Powder, Granules
Model : NNL-8DA (Inner tank hanging type)
Type : Reversible paddle type
Appliation : Suitable for powder not much sticking to the tank wall. Longer lasting & highly stable.
Power : 100-110VAC or 200-220VAC 50/60Hz
Rate of rotation : 1 rpm/50Hz
|
Power consumption : 4W
Detection torque : 1470-1764 N.m x 10e-4
Mounting : Inner tank hanging type. Suspended in a tank with 40A pipe.
Lead cable length : 350 mm
Allowable temperature : Below 50°C (in a tank).
Allowable pressure : 19.6 kPa
Enclosure rating : IP55
|
|
NNM-8B
|
|
Brand : Kansai
Media : Powder, Granules
Model : NM-8B (Standard flange type)
Type : Reversible paddle type
Appliation : Suitable for powder not much sticking to the tank wall.
Power : 100-110VAC or 200-220VAC 50/60Hz
Rate of rotation : 1 rpm/50Hz
|
Power consumption : 4W
Detection torque : 1470-1764 N.m x 10e-4
Mounting : Flange type
Flange size : JIS5K65A equivalent
Allowable temperature : Below 50°C (in a tank).
Allowable pressure : 19.6 kPa
Enclosure rating : IP55
|
|
NNM-SC
|
|
Brand : Kansai
Media : Powder, Granules
Model : NNM-SC (Screwed joint type)
Type : Reversible paddle type
Appliation : Suitable for powder not much sticking to the tank wall. Small hopper level switch.
Power : 100-110VAC or 200-220VAC 50/60Hz
Rate of rotation : 1 rpm/50Hz
|
Power consumption : 4W
Detection torque : 1470-1764 N.m x 10e-4
Mounting : Screwed joint type, make the tank diameter Ø34 in mounting.
Allowable temperature : Below 50°C (in a tank).
Allowable pressure : 19.6 kPa
Enclosure rating : IP55
|
|
NNM-8BA
|
|
Brand : Kansai
Media : Powder, Granules
Model : NNM-8BA (Adjustable shaft)
Type : Reversible paddle type
Appliation : Suitable for powder not much sticking to the tank wall.Upper limit detection.
Power : 100-110VAC or 200-220VAC 50/60Hz
Rate of rotation : 1 rpm/50Hz
|
Power consumption : 4W
Detection torque : 1470-1764 N.m x 10e-4
Mounting : Vertical falnge type
Flange size : JIS5K65A equivalent
Allowable temperature : Below 50°C (in a tank).Heat resistant type can be available.
Allowable pressure : 19.6 kPa
Enclosure rating : IP55
|
|
NNM-8BS
|
|
Brand : Kansai
Media : Powder, Granules
Model : NNM-8BS (Protective-tube extension type)
Type : Rotary paddle type
Appliation : Suitable for powder not much sticking to the tank wall.
Power : 100-110VAC or 200-220VAC 50/60Hz
Rate of rotation : 1 rpm/50Hz
|
Power consumption : 4W
Detection torque : 1470-1764 N.m x 10e-4
Mounting : Vertical,horizontal and diagonal monting can be selected.
Flange size : JIS5K65A equivalent
Allowable temperature : Below 50°C (in a tank). Heat resistant type can be available.
Allowable pressure : 19.6 kPa
Enclosure rating : IP55
|
|
NNM-8BH
|
|
Brand : Kansai
Media : Powder, Granules
Model : NNM-8BH (Heat resistant type)
Type : Reversible paddle type
Appliation : Suitable for powder not much sticking to the tank wall. longer lasting & highly stable.
Power : 100-110VAC or 200-220VAC 50/60Hz
Rate of rotaton : 1 rpm/50Hz
|
Power consumption : 4W
Detection torque : 1470-1764 N.m x 10e-4
Mounting : Horizintal mounting
Flange size : JIS5K65A equivalent
Allowable temperature : Below 180°C (in a tank).
Allowable pressure : 19.6 kPa
Enclosure rating : IP55
|
|
NNM-8BN(S)
|
|
Brand : Kansai
Media : Powder, Granules
Model : NNM-8BN(S) (Diagonal flange type)
Type : Reversible paddle type
Appliation : Suitable for powder not much sticking to the tank wall. Longer lasting and highly stable.
Power : 100-110VAC or 200-220VAC 50/60Hz
Rate of rotation : 1 rpm/50Hz
|
Power consumption : 4W
Detection torque : 1470-1764 N.m x 10e-4
Mounting : Diagonal mounting.Best to mount at the conical area directly, 45° angle.
Flange size : JIS5K65A equivalent
Allowable temperature : Below 50°C (in a tank).
Allowable pressure : 19.6 kPa
Enclosure rating : IP55
|
|
LS
|
|
Brand : Kansai
Media : Powder, Granules
Model : LS (Standard)
Type : Small rotatry paddle type level switch
Appliation : Suitable for small tank
Power : 100-110VAC or 200-220VAC 50/60Hz
Power consumption : 1.5W
|
Paddle rotation : 0.83 rpm (50Hz) / 1.00 rpm (60Hz)
Detection torque : 170-270 N.m x10e-4
Paddle type : Unfolding paddle
Mounting : Horizontal mounting
Flange size : JIS5K65A equivalent
Temperature : Below 50°C (in a tank)
Enclosure rating : IP55
|
|
LS-K
|
|
Brand : Kansai
Media : Powder, Granules
Model : LS-K (Square flange)
Type : Small rotatry paddle type level switch
Appliation : Suitable for small tank
Power : 100-110VAC or 200-220VAC 50/60Hz
Power consumption : 1.5W
|
Paddle rotation : 0.83 rpm (50Hz) / 1.00 rpm (60Hz)
Detection torque : 170-270 N.m x10e-4
Paddle type: Unfolding paddle
Mounting : Horizontal mounting
Flange size : 80 x 80 mm
Temperature : Below 50°C (in a tank)
Enclosure rating : IP55
|
|
