NL-8B

Quick View

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NL-8B (Standard)

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50 Hz

Power consumption : 4W

Detection torque : 1470-1764 N.m x 10e-4

Mounting : Standard flange type

Allowable temperature : Below 50°C (in a tank)

Allowable pressure : 19.6 kPa

Enclosure rating : IP55



NL-8BH

Quick View

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NL-8BH (Heat resistant type)

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50Hz

Power consumption : 4W

Detection torque : 1470-1764 N.m x 10e-4.

Mounting : Standard flange type

Allowable temperature : 250°C (in a tank). Optional air or water cooled type can operate at the higher temperature.

Allowable pressure : 19.6 kPa

Enclosure rating : IP55

NL-15B

Quick View

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NL-15B (Withstand load type)

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall

Function : Lower limit detection of a large tank. Level switch

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50Hz



Power consumption : 4W

Detection torque : 1470-1764 N.m x 10e-4

Mounting : Standard flange type.Level switch of withstand load type, mounted in a lower part of silo.

Allowable temperature : Below 50°C (in a tank). Both heat resistant & protective  tube extension type can be manufactured.

Allowable pressure : 19.6 kPa

Enclosure rating : IP55



NL-8DA

Quick View

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NL-8DA (Inner tank hanging type)

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall.Can be used under varied conditions.

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50Hz

Powerconsumption : 4W

Detection torque : 1470-1764 N.m x 10e-4

Mounting : Inner tank hanging type. Suspended in a tank with 40A pipe.

Allowable temperature : Below 50°C (in a tank).

Allowable pressure : 19.6 kPa

Enclosure rating : IP55





NM-8B

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NM-8B (Standard flange type)

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall.

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50Hz



Power consumption : 4W

Detection torque : 1470-1764 N.m x 10e-4

Mounting : Flange type

Flange size : JIS5K65A equivalent

Allowable temperature : Below 50°C (in a tank).

Allowable pressure : 19.6 kPa

Enclosure rating : IP55





NM-SC

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NM-SC

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall.

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50Hz

Power consumption : 4W

Detection torque : 1470-1764 N.m x 10e-4

Mounting : Screwed joint type, make the tank diameter Ø34 in mounting.

Allowable temperature : Below 50°C (in a tank).

Allowable pressure : 19.6 kPa

Enclosure rating : IP55

NL-8BA

Quick View

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NL-8BA (Adjustable shaft)

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall.Upper limit detection.

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50Hz

Power consmption : 4W

Detection torque : 1470-1764 N.m x 10e-4

Mounting : Vertical falnge type

Flange size : JIS5K65A equivalent

Allowable temperature : Below 50°C (in a tank).Heat resistant type can be available.

Allowable pressure : 19.6 kPa

Enclosure rating : IP55

NL-8BS

Quick View

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NL-8BS (Protective-tube extension type)

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall.

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50Hz

Power consumption : 4W

Detection torque : 1470-1764 N.m x 10e-4

Mounting : Vertical,horizontal and diagonal monting can be selected.

Flange size : JIS5K65A equivalent

Allowable temperature : Below 50°C (in a tank).Heat resistant type can be available.

Allowable pressure : 19.6 kPa

Enclosure rating : IP55

KLT

Quick View

View Full Details

Brand : Kansai

Media : Powder, Granules, Liquid, Surface Interface

Model : KLT (Amplifier built-in type)

Type : Capacitance type

Application : Suitable for condition such as high temperature and pressure, strong acid, strong alkali, conductive, insulating.

Power source :105/210VAC   ±15% 50/60Hz. DC24V is available as option.



Power consumption : 4VA

Output signal : DC 4-20mA (Resistive load), max.500Ω (-)grounded

Sensitivity : 10pF . 30pF . 300pF . 3000pF (F.S)

Accuracy : 1%

Operating temp. : -20°C~70°C

Allowable pressure : 980kPa

Mounting : Vertical mounting

Enclosure rating : Equivalent to IP-55







NM-8BA

View Full Details

Brand : Kansai

Media : Powder, Granules

Model : NM-8BA (Adjustable shaft type)

Type : Rotary paddle type

Appliation : Suitable for powder not much sticking to the tank wall.

Power : 100-110VAC or 200-220VAC 50/60Hz

Rate of rotation : 1 rpm/50Hz

Power consumption : 4W

Detection torque : 1470-1764 N.m x 10e-4

Mounting : Vertical mounting

Flange size : JIS5K65A equivalent

Allowable temperature : Below 50°C (in a tank).Heat resistant type can be available.

Allowable pressure : 19.6 kPa

Enclosure rating : IP55
