Most Advanced Laser Displacement Sensor                                                                            Product Technology


Catalog optoNCDT Laser Sensors
Data sheet optoNCDT 2300


The optoNCDT 2300 is the latest high-end model of laser triangulation sensors from Micro-Epsilon. The new series offers an adjustable measuring rate up to 49.140 kHz. An impressive and worldwide unique fact regarding this sensor class is that the electronics of the system have already been integrated in the compact sensor. The optoNCDT 2300 is ideal for the most challenging applications in either diffuse or specular mode and can even measure the thickness of transparent materials.


 Characteristics

  •  High speed 49,000 hz real time measurement
  •  ARTSC advanced real time surface compensation
  •  New improved optics
  •  New improved CCD
  •  Dual measurement mode 2 in 1 (diffuse and specular)
  •  Thickness mode built in
  •  Most compact design, single piece without external controller
  •  Advance signal processing ( filters, stats, trigger, synch...)
  •  New Ethernet, Ethercat, RS422, Profinet, EtherNet/IP interface
  •  Embedded set up browser
  •  Various ranges, blue and LL anti speckle option



Application flexibility

The optoNCDT 2300 can be operated in several measurement modes: in standard mode for displacement measurement of diffuse reflecting materials or with a special alignment mode to measure directly reflecting surfaces. Furthermore, the laser triangulation sensor can be used for one-sided thickness measurement of transparent materials (multi-peak evaluation). Therefore, the software provides a comprehensive materials database that is editable and expandable.

The A-RTSC (Advanced Real Time Surface Compensation) feature is a further development of RTSC technology and improves the surface compensation capability. This means the sensor is not influenced by rapidly changing surface reflections and provides stable measurement results.

Other models of the optoNCDT 2300 series:

 Blue Laser Sensors

 Laser Line (LL) Sensors

 Long-range Sensors



Unique ease of use

All optoNCDT 2300 laser sensors are operated using an intuitive web interface. This web interface can be accessed via Ethernet, enabling the user to make settings for the processing of measured values and signals, e.g. peak selection, filter and masking features for the video signal.




Highest performance in laser triangulation

The optoNCDT 2300 is the high performance version of Micro-Epsilon laser triangulation sensors and offers an adjustable measuring rate of up to 49.14kHz. The optoNCDT 2300 is used for high speed applications such as the monitoring of vibrations or measurements on challenging surfaces. Due to their high resolution, sub-micrometer measurement accuracies are possible.






DOWNLOADS

 Catalog optoNCDT laser Sensors (PDF, 4.4 MB)
 Data sheet optoNCDT 1700BL

Blue Laser triangulation sensor

  Measuring ranges Resolution Linearity Measuring rate
20 - 1000 mm 0.005 % F.S.O. ± 0.08 % F.S.O. 2.5 kHz
FSO = of full scale output


Process controllers and interface cards

Universalcontroller for up to six sensorsIF2001USB--34pxRS422/USB Converter IF2001/USBRS422-USB-Converter-35px4 Channel RS422/USB Converter IF2004/USBIF2008 - Interface card

The new technology Blue Laser allows the sensors, absolutely precise and reliable measurement results on red-glowing metals and glowing silicium. The blue-violet laser offers decisive advantages. Even in the case of measurements being effected on organic matters such as veneers, wood, or skin, the blue laser makes an important contribution regarding precision. While allowing more stability, the blue laser light does not penetrate the measuring object due to the reduced blue-violet laser.

Blue Laser sensors belonging to the series optoNCDT 1700BL are designed for fast distance, displacement and position measurement on red-glowing metals. The sensors are equipped with new high-end lenses, laser control and evaluation algorithms.

Details

Measuring ranges (mm):
20 | 50 | 200 | 500 | 750 | 1000
Linearity max. 16µm
Resolution max. 1.5µm
Blue Laser technology
Compact, with integrated controller
Configurable measuring rate up to 2.5kHz
Real-time compensation for changing surfaces (RTSC)
Freely programmable limit switch









DOWNLOADS

 Catalog optoNCDT laser Sensors (PDF, 4.4 MB)
 Data sheet optoNCDT 1710-1000

Intelligent laser sensor with 1,000mm measuring range


  Measuring ranges Resolution Linearity Measuring rate
optoNCDT1710-1000.jpg (1 KB)) Intelligent laser sensor with 1,000mm measuring range
1000 mm 0.01 % F.S.O. ± 0.1 % F.S.O. 2.5 kHz
FSO = of full scale output


Process controllers and interface cards

Universalcontroller for up to six sensorsIF2001USB--34pxRS422/USB Converter IF2001/USBRS422-USB-Converter-35px4 Channel RS422/USB Converter IF2004/USBIF2008 - Interface card

The optoNCDT 1710-1000 laser sensors are unrivalled in measurement performance worldwide. The sensor can measure over a working range of 1,000mm. The start of measurement is 1,000mm from the sensor body which means that objects upto 2m in distance can be measured. The controller is integrated into the housing of the sensor which means that external electronic processing is not required. The sensor operates with automatic, real time surface compensation, RTSC which auto adapts the laser intensity to the surface being measured. Additionally built in, programmable limit switch give the sensor further integration flexibility.

Application areas of the sensor are:

  • Harsh environments
  • Large parts or areas where a large stand off are required
  • Target in vacuum – the sensor can measure through viewing windows
  • High object temperatures
  • In process measurements on difficult surfaces

Details

Measuring ranges (mm):
1,000
Linearity max. +/- 1mm
Resolution max. 100µm
Start of measurement range, SMR: 1m
Configurable measuring rate up to 2.5kHz
Real-time compensation for changing surfaces (RTSC)
Freely programmable limit switch





DOWNLOADS

 Catalog optoNCDT laser Sensors (PDF, 4.4 MB)
 Data sheet optoNCDT 1700LL

High accuracy laser sensor for shiny and rough surfaces


  Measuring ranges Resolution Linearity Measuring rate
laser-sensor-opto-ild-1700LL.jpg (1 KB)) High accuracy laser sensor for shiny and rough surfaces
2 - 50 mm 0.005 % F.S.O. ± 0.1 % F.S.O. 2.5 kHz
FSO = of full scale output


Process controllers and interface cards

Universalcontroller for up to six sensorsIF2001USB--34pxRS422/USB Converter IF2001/USBRS422-USB-Converter-35px4 Channel RS422/USB Converter IF2004/USBIF2008 - Interface card

The optoNCDT 1700 LL is a special laser sensor for shiny metals and structured surfaces. The oval laser spot facilitates a particularly easy and precise measurement on shiny metal surfaces or structured objects.

Details

Measuring ranges (mm):
2 |10 | 20 | 50
Linearity max. 2µm
Resolution max. 0.1µm
Precise measurements on metal surfaces
Integrated controller
Distance measurement on structured surfaces
Adjustable measuring rate up to 2.5kHz
Real-time compensation on changing surfaces (RTSC)
Special lens for oval laser spot





DOWNLOADS

 Catalog optoNCDT laser Sensors (PDF, 4.4 MB)
 Data sheet optoNCDT 1700

Intelligent laser sensor with integrated controller for industrial applications


  Measuring ranges Resolution Linearity Measuring rate
laser-sensor-opto-ild-1700.jpg (1 KB)) Intelligent laser sensor with integrated controller for industrial applications
2 - 750 mm 0.005 % F.S.O. ± 0.08 % F.S.O. 2.5 kHz
FSO = of full scale output


Process controllers and interface cards

Universalcontroller for up to six sensorsIF2001USB--34pxRS422/USB Converter IF2001/USBRS422-USB-Converter-35px4 Channel RS422/USB Converter IF2004/USBIF2008 - Interface card

The optoNCDT 1700 is laser displacement sensor with multi-functional features. The unique Real-Time Surface Compensation (RTSC) feature enables measurement against a wide range of material surfaces.
Its unique compact design makes the optoNCDT 1700 ideal for all industrial applications in automation and OEM production equipment.

Details

Measuring ranges (mm):
2 | 10 | 20 | 40 | 50 | 100 | 200 | 250 | 500 | 750
Linearity max. 2µm
Resolution max. 0.1µm
Compact, with integrated controller
Configurable measuring rate up to 2.5kHz
Real-time compensation for changing surfaces (RTSC)
Freely programmable limit switch
