Powerful laser distance sensor for industrial applications                                                                   Product Technology

The optoNCDT ILR2250-100 laser distance sensor is designed for precise distance measurements in industrial environments. A reflector attached to the measuring object enables distance measurements max to 150m. Without reflector, the sensor detects measuring ranges max to 100m. The integrated AUTO measurement mode enables reliable measurements even on dark, partly reflecting and remote measuring objects. Therefore, the ILR2250 sensors can be used for distance measurements on numerous surfaces.



 Characteristics

  •  Large measuring range up to 100 m (up to 150 m with reflector)
  •  High accuracy and signal stability
  •  Linearity ±0.5 mm
  •  Resolution 0.1 mm
  •  Repeatability < 300 µm
  •  Analog output and digital interfaces (RS422 / USB)
  •  Compact & lightweight design
  •  Ideal for industrial applications


Compact sensor design for versatile measurement tasks

The laser distance sensor impresses with high speed and is, among other things, used in logistics and automation technology, the metals industry and production monitoring. The entire aluminum die-cast housing and its low weight enable easy integration in numerous industrial environments.
The ILR2250 detects distances up to 100 m (without reflector), with reflector up to 150 m. This means the sensor is suitable for measurements tasks in logistics, factory and plant automation, as well as in drone applications for distance measurements from the air.








IF2030 interface module for Industrial Ethernet connection
The IF2030 interface modules are designed for easy connection of Micro-Epsilon sensors to Industrial Ethernet controllers, e.g., plant control systems. The PROFINET and EthernetIP modules are compatible with sensors that output data via an RS422 or RS485 interface. These modules operate on the sensor side with up to 4 MBaud and have two network connections for different network topologies. Installation in switching cabinets is via a DIN rail.


 The interface modules are compatible with multiple sensors:

  •  optoNCDT 1320, optoNCDT 1420, optoNCDT 1750, optoNCDT 1900, optoNCDT 2300
  •  confocalDT 242x, confocalDT 24x1
  •  optoCONTROL 2520
  •  colorCONTROL ACS7000
  •  inertialSENSOR ACC5703, inertialSENSOR INC5701
  •  capaNCDT 6120
  •  induSENSOR MSC7x0x


 Characteristics

  •  Ideal for confined spaces due to a compact housing
  •  Compatible with sensors with RS422 and RS485 interfaces
  •  Two network connections for different network topologies
  •  Data rate up to 4 MBaud







IF2008/ETH Interface module for Ethernet connection with up to 8 sensors
The IF2008/ETH interface module is designed for multi-channel applications. This module allows for up to 8 Micro-Epsilon sensors or encoders with RS422 interface to be integrated into an Ethernet network. Furthermore, the converter offers 4 programmable switching inputs/outputs (TTL and HTL logic) as well as 10 indicator LEDs, which show the channel or device status directly on the device. Parameter setting of the interface module can be easily done via the web interface.


 The interface module is compatible with multiple sensors:

  •  optoNCDT 1420, optoNCDT 1750, optoNCDT 1900, optoNCDT 2300
  •  confocalDT 2421, confocalDT 2422, confocalDT 2451, confocalDT 2461, confocalDT 2471
  •  optoCONTROL 2520


 Characteristics

  •  Robust interface converter for multi-channel applications (8-channel system)
  •  Compatible with Micro-Epsilon sensors with RS422 interface
  •  High data output up to 200 kHz
  •  4 programmable switching inputs/outputs
  •  LED status display
  •  Parameter set up via web interface







IF2008/PCIE - Interface card

The IF2008/PCI interface card is designed for installation in PCs and enables the synchronous capture of digital sensor signals and encoders. The IF2008/PCIE interface card is developed for installation in PCs with PCI Express slots.The absolutely synchronous data acquisition plays an important role particularly for planarity or thickness measurement tasks. The interface card enables the synchronous capture of four digital sensor signals and two encoders. The data are stored in a FIFO memory in order to enable resource-saving processing in the PC in blocks.



Additionally, the IF2008E expansion board offers two sensor inputs, two ADC inputs, four optocoupler input and four optocoupler outputs. In sum, six digital sensors, two analog sensors and two encoders can be connected using both cards.


 Characteristics

  •  4x digital signals and 2x encoders with basic board
  •  6x digital signals, 2x encoders, 2x analog signals and 8x I/O signals together with the expansion board
  •  FIFO data memory
  •  PCI plug-in cards
  •  Synchronous data acquisition
  •  IF2008PCIe with PCI Express interface







4 Channel RS422/USB Converter IF2004/USB
The RS422/USB converts digital signals from up to 4 optical sensors into a USB data packet. The new converter has 4 trigger inputs and a trigger output for connecting additional converters.The data are output via an USB interface. The converter as well as the connected sensor are parametrisable by software.


 Characteristics

  •  4x digital signals via RS422
  •  4 trigger inputs, 1 trigger output
  •  Synchronous data aquisition
  •  USB interface
