SP5000 Series Lineup / Specifications

Module Configuration

Premium Display	Advanced Display	Open Box	Power Box	Standard Box
Industry's top-class display with high display quality and versatile functions	Sophisticated display with high display quality	Enable to use Windows Applications via HMI	Reliable real-time OS installed in HMI High performance & Extended HMI	Reliable real-time OS installed in HMI High performance HMI
SP-5800WC, SP-5700WC, SP-5700TP, SP-5660TP, SP-5600TP, SP-5500TP	SP-5600TA, SP-5600WA, SP-5500WA, SP-5400WA	SP-5B41	SP-5B10	SP-5B00

Display Module

Display Type	Product Name	Model No.	Display Size	Display Colors	Touch Panel Type	Front USB	Brightness Sensor	Auto Scaling	Details
Premium	SP-5800WC *1	PFXSP5800WCD	19" Wide (FWXGA)	16 million	Projected Capacitive (multi-touch)	Yes	Yes	Yes	Datasheet （PDF）(link is external)
	SP-5700WC *1	PFXSP5700WCD	15" Wide (FWXGA)		Projected Capacitive (multi-touch)
	SP-5700TP	PFXSP5700TPD	15" (XGA)		Analog Resistive Film (multi-touch)
	SP-5660TP *2	PFXSP5660TPD	12" (XGA)
	SP-5600TP	PFXSP5600TPD	12" (XGA)
	SP-5500TP	PFXSP5500TPD	10" (SVGA)
Advanced	SP-5600TA	PFXSP5600TAD	12" (XGA)	262,144	Analog Resistive Film	No	No	No
	SP-5600WA	PFXSP5600WAD	12" Wide (WXGA)
	SP-5500WA	PFXSP5500WAD	10" Wide (WXGA)
	SP-5400WA	PFXSP5400WAD	7" Wide (WVGA)

*1SP-5800WC, SP-5700WC and SP-5600TA are not compatible with SP-5B40 (End of Sale: Mar. 30, 2018).

*2SP-5660TP is not compatible with SP-5B10 (Power Box) and SP-5B00 (Standard Box).

Box Module

Box Type	Product Name	Model No.	Windows Application	Expansion Unit	Sound Output	AUX Output	Details
Open	SP-5B41	PFXSP5B41	Yes	Yes	Yes	Yes	Datasheet （PDF）(link is external)
Power	SP-5B10 *3	PFXSP5B10	-	Yes	Yes	Yes
Standard	SP-5B00 *3	PFXSP5B00	-	-	-	-

*3SP-5B10 (Power Box) and SP-5B00 (Standard Box) are not compatible with SP-5660TP.

Display Module x Box Module

Screen Size	Product Name	Bright- ness Sensor/ Auto Scaling/ Front USB/ Multi- touch	Win- dows Apps	Video/ Sound	Remov- able System	CFast (Stor- age)	SD (Stor- age)	USB Type A	USB mini B	SIO	Ether -net	Rated Voltage	Details
19" Wide (FWXGA)	SP-5800WC + SP-5B41	Yes	Yes	Yes	Yes	x 1	x 1	x 4	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5800WC + SP-5B10	Yes	-	-	Yes	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5800WC + SP-5B00	Yes	-	-	-	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
15" Wide (FWXGA)	SP-5700WC + SP-5B41	Yes	Yes	Yes	Yes	x 1	x 1	x 4	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5700WC + SP-5B10	Yes	-	-	Yes	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5700WC + SP-5B00	Yes	-	-	-	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
15" (XGA)	SP-5700TP + SP-5B41	Yes	Yes	Yes	Yes	x 1	x 1	x 4	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5700TP + SP-5B10	Yes	-	-	Yes	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5700TP + SP-5B00	Yes	-	-	-	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
12" (XGA) Wireless LAN Model	SP-5660TP + SP-5B41	Yes	Yes	Yes	Yes	x 1	x 1	x 4	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
12" (XGA)	SP-5600TP + SP-5B41	Yes	Yes	Yes	Yes	x 1	x 1	x 4	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5600TP + SP-5B10	Yes	-	-	Yes	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5600TP + SP-5B00	Yes	-	-	-	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
12" (XGA)	SP-5600TA + SP-5B41	-	Yes	Yes	Yes	x 1	x 1	x 3	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5600TA + SP-5B10	-	-	-	Yes	-	x 1	x 2	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5600TA + SP-5B00	-	-	-	-	-	x 1	x 2	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
12" Wide (WXGA)	SP-5600WA + SP-5B41	-	Yes	Yes	Yes	x 1	x 1	x 3	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5600WA + SP-5B10	-	-	-	Yes	-	x 1	x 2	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5600WA + SP-5B00	-	-	-	-	-	x 1	x 2	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
10" (SVGA)	SP-5500TP + SP-5B41	Yes	Yes	Yes	Yes	x 1	x 1	x 4	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5500TP + SP-5B10	Yes	-	-	Yes	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5500TP + SP-5B00	Yes	-	-	-	-	x 1	x 3	x 2	x 2	x 2	12 to 24 Vdc	Display/ Box
10" Wide (WXGA)	SP-5500WA + SP-5B41	-	Yes	Yes	Yes	x 1	x 1	x 3	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5500WA + SP-5B10	-	-	-	Yes	-	x 1	x 2	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5500WA + SP-5B00	-	-	-	-	-	x 1	x 2	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
7" Wide (WVGA)	SP-5400WA + SP-5B41	-	Yes	Yes	Yes	x 1	x 1	x 3	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5400WA + SP-5B10	-	-	-	Yes	-	x 1	x 2	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box
	SP-5400WA + SP-5B00	-	-	-	-	-	x 1	x 2	x 1	x 2	x 2	12 to 24 Vdc	Display/ Box

Model Number List (PDF)

Bezel Color *4

Front Color

Front Color	Black	Off-white	Beige	Silver
Front Panel	Black （PANTONE 432C）	Off-white （PANTONE Cool Gray 1C）	Beige （PANTONE 7535C）	Silver （PANTONE 8401C）
Front Bezel	Black	Standard（Silver）	Standard（Silver）	Standard（Silver）

*4SP-5800WC and SP-5700WC support a front color silver (no front USB) model only.

Coating *5

Peace of mind in a harsh environment. "Coated models" feature more protection from corrosion.

Extended product lifetime for use in harsh environments compared to uncoated products. Corrosion resistance is also improved.

*5Except for SP-5800WC and SP-5700WC.

Model Numbers

Display Module

*65 simultaneous touch

*72 simultaneous touch

*8SP-5800WC and SP-5700WC support a front color silver (no front USB) model only.

*9For Premium Display with F1 selected, an enhanced front USB cover with a screw is already installed.

*10The overlay types from F5 to F8 can be selected for Premium Display only.

*11When a coated model is selected with standard silver front color, choose F0.

Box Module

SP5000 Series

Flagship Model of HMI for extensive use of information

How can you fully utilize only the information you need from scattered big data? SP5000 Series provides Smart Portal, a window that optimally displays information in response to a demand for increasingly sophisticated information utilization as a new solution.

GP-3510T AGP3510-T1-AF(PFXGP3510TAA)

DOWNLOADS

Datasheet

Functional Specifications

Display Type	TFT Color LCD
Display Size	10.4"
Resolution	800 x 600 pixels (SVGA)
Dot pitch	W0.264 x H0.264 mm [W0.01 x H0.01 in.]
Effective Display Area	W211.2 x H158.4 mm [W8.31 x H6.24 in.]
Display Colors	65,536 Colors (No blink)/16,384 Colors (Blink)
Backlight	CCFL (Replaceable)
Brightness Control	8 Levels (Adjusted with the touch panel)
Contrast Control	Not applicable
Backlight Service Life	50,000 hrs. or more (continuous operation at 25℃ before backlight brightness decreases to 50% or backlight starts to blink)
Language Fonts	Japanese: 6,962 (JIS Standards 1 & 2) (including 607 non-kanji characters), ANK: 158 (Korean fonts, Simplified Chinese and Traditional Chinese fonts are downloadable.
Character Sizes	Standard font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts, Stroke font: 6 to 127 pixel fonts, Image font: 8 to 72 pixel fonts
Font Sizes	Standard font: Width can be expanded up to 8 times., Height can be expanded up to 8 times.*1
8 x 16 dots	100 char. X 37 rows
16 x 16 dots	50 char. X 37 rows
32 x 32 dots	25 char. X 18 rows
8 x 8 dots	100 char. X 75 rows
Program Area	FLASH EPROM 132 KB
Number of Step	Equivalent to 15,000 steps*2
Variable Area	SRAM 64 KB (uses lithium battery)*3
Application Memory	FLASH EPROM 16 MB*4
Data Backup	SRAM 320KB (uses lithium battery)*5
Clock Accuracy	±65 sec./month (deviation at room temperature and power is OFF)*6
Touch Panel Type	Resistive Film (analog)
Touch Panel Resolution	1,024 X 1,024
Touch Panel Service Life	1,000,000 times or more
Serial (COM1)	RS-232C/422/485, Asynchronous Transmission, Data Length: 7 or 8 bit, Parity: none, Even or Odd, Stop Bit: 1 or 2 bit, Data Transmission Speed: 2,400 bps to 115.2 kbps, Connector: D-Sub9 (plug)
Serial (COM2)	RS-422/485, Asynchronous Transmission, Data Length: 7 or 8 bit, Parity: none, Even or Odd, Stop Bit: 1 or 2 bit, Data Transmission Speed: 2,400 bps to 115.2 kbps, 187.5kbps (MPI), Connector: D-Sub9 (socket)
Ethernet (LAN)	IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX, Connector: Modular jack (RJ-45) x 1
Expansion Unit 1	Communication Expansion Unit x 1
Expansion Unit 2	VM/DVI Input Expansion Unit x 1
USB (TYPE-A)	Conforms to USB1.1 (TYPE-A) x 2, Power Supply Voltage: DC 5 V ±5 %, Output Current: 500 mA or less, Communication Distance: 5 m or less
Expansion Memory	Function Expansion Memory x 1 (on internal circuit board)
CF Card	Compact Flash CF Card Slot (TYPE-II) X 1
Sound Output	Speaker Output, 70mW (Rated Load: 8Ω, Frequency: 1kHz), Connector: 2-piece terminal block (AUX) X 1
AUX Input/Output	Alarm Output, RUN Output, Buzzer Output, Rated Voltage: DC24V, Rated Current: 50mA, Remote Reset Input, Input Voltage: DC24V, Connector: 2-piece terminal block (AUX) X 1

*1 Other font sizes can be set up with the Editor software.

*2 Up to 60,000 steps can be converted in software. However, this reduces internal memory capacity (for screen data) by 1 MB.

*3 A Lithium battery's lifetime is:
10 years when the battery's ambient temperature is 40 oC or less.
4.1 years when the battery's ambient temperature is 50 oC or less.
1.5 years when the battery's ambient temperature is 60 oC or less.
When used for back up: Approximately 100 days, with a fully charged battery.
Approximately 6 days, with a half-charged battery.

*4 Capacity available for user application. 8 MB available if the revision of the unit is earlier than Rev. 4, or GP-Pro EX Ver. 2.5 or earlier is used.

*5 A Lithium battery's lifetime is:

10 years when the battery's ambient temperature is 40 oC or less.
4.1 years when the battery's ambient temperature is 50 oC or less.
1.5 years when the battery's ambient temperature is 60 oC or less.
When used for back up: Approximately 100 days, with a fully charged battery.
Approximately 6 days, with a half-charged battery.

*6 Depending on the operating temperature and age of unit, the clock can deviate from -380 to +90 sec./month. For systems where this level of deviation is a problem, the user should monitor and make adjustments when required.

General Specifications

International Safety Standards
Rated Input Voltage	AC 100 to 240V
Input Voltage Limits	AC 85 to 264V
Rated Frequency	50/60 Hz
Rated Frequency Range	40 to 72 Hz
Allowable Voltage Drop	Shorter than 1cycle (Voltage drop interval must be 1 second or more.)
Power Consumption	AC 100 V: 90 VA or less, AC 240 V: 108 VA or less
In-Rush Current	60 A (max.)
Voltage Endurance	AC1,500V 20mA for 1 minute, (between charging and FG terminals)
Insulation Resistance	DC500V 10MΩ (min.), (between charging and FG terminals)
Surrounding Air Temperature	0 to 50 °C (32 to 122 °F)
Storage Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Humidity	10 to 90% RH (Wet bulb temperature: 39℃ max. - no condensation.)
Storage Humidity	10 to 90% RH (Wet bulb temperature: 39℃ max. - no condensation.)
Dust	0.1mg/m³ and below (non-conductive levels)
Pollution Degree	For use in Pollution Degree 2 environment
Atmosphere	Free of corrosive gases
Air Pressure (altitude range)	800 to 1,114 hPa (2,000 m [6,561ft.] above sea level or less)
Vibration Resistance	IEC/EN61131-2 compliant, 5 to 9Hz Single amplitude 3.5mm [0.14in.], 9 to 150Hz Fixed acceleration: 9.8m/s², X,Y,Z directions for 10 cycles (100 minutes)
Concussion Resistance	IEC/EN61131-2 compliant, 147 m/s², X, Y, Z directions for 3 times
Noise Immunity	Noise Voltage: 1,500Vp-p, Pulse Duration: 1µs, Rise Time: 1ns, (via noise simulator)
Electrostatic Discharge Immunity	Contact Discarge Method: 6kV (IEC/EN61000-4-2 Level 3)
Grounding	Functional grounding: Grounding resistance of 100Ω, 2mm² or thicker wire, or your country's applicable standard. (Same for FG and SG terminals)
Structure	Equivalent to IP65f NEMA #250 TYPE 4X/13 (Front surface of embedded panel) *7
Installation Configuration	Embedded panel
Cooling Method	Natural air circulation
Weight Approx.	2.5 kg [5.5 lb] or less (display unit only)
External Dimensions	W270.5 x H212.5 x D57 mm [W10.65 x H8.37 x D2.24 in.]
Panel Cut Dimensions	W259 x H201 mm [W10.2 x H7.91 in.], Panel thickness area: 1.6 to 10 mm [0.06 to 0.39 in.] *8

*7 The front face of the GP unit, installed in a solid panel, has been tested using, conditions equivalent to the standards shown in the specification. Even though the, GP unit's level of resistance is equivalent to these standards, oils that should have, no effect on the GP can possibly harm the unit. This can occur in areas where either, vaporized oils are present, or where low viscosity cutting oils are allowed to adhere, to the unit for long periods of time. If the GP's front face protection sheet becomes, peeled off, these conditions can lead to the ingress of oil into the GP and separate, protection measures are suggested., Also, if non-approved oils are present, it may cause deformation or corrosion of the, front panel’s plastic cover. Therefore, prior to installing the GP be sure to confirm the, type of conditions that will be present in the GP's operating environment., If the installation gasket is used for a long period of time, or if the unit and its gasket, are removed from the panel, the original level of the protection cannot be guaranteed. To maintain the original protection level, be sure to replace the installation gasket, regularly.

*8 Regarding dimensional tolerance, everything +1/-0 mm [+0.04/-0 in.] and R in angle are below R3 [R0.12 in.].

External Dimensions / Interfaces / Panel Cut-out / Cable Attached Dimensions

10.4"

Multi-Port Touchscreen Operator Interface with Simultaneous Driver Support

	- Display Type and Size:	TFT Color LCD (10.4")
	- Display Colors:	65,536 Colors
	- Display Area:	W 211.2 x H 158.4 mm [W8.31 x H 6.24 in]
	- Touch Screen:	Resistive Film (analog) 1024 x 1024 resolution
	- Backlight:	User replaceable CCFL
	- Storage Temperature:	-20 to 60 deg C (-4 to 140 deg F)
	- Environmental Ratings:	IP65f, NEMA Type 4x/13
	- Certifications:	CE, UL Listed C1D2, RoHS,ATEX

PRODUCT SPECIFICATIONS
Part Number to Order:	AGP3500-T1-D24 AGP3500-T1-D24-M*	AGP3500-T1-AF AGP3500-T1-AF-M*	AGP3510-T1-AF
Display Type and Size:	640 x 480 pixels (VGA)		800 x 600 pixels
CF Card	1 Slot Type II
Serial Ports (COMC1):	RS232C/422/485
Serial Ports (COMC2):	RS-422/485
Ethernet:	Yes
USB (1):	Type-A (2.0)
USB (2):	Type-A (2.0)
Brightness Controls:	8 levels of adjustment
Programming Memory:	16mb Flash EPROM
Backup Memory:	320kb SRAM
Ambient Operating Temperature:	0 to 50 deg C (32 to 122 deg F)
Input Voltage:	24 VDC	100 Vac to 240Vac	100 Vac to 240Vac
Power Consumption:	24 VDC <2.08A	100Vac: <0.9A 240Vac: <0.45A	100Vac: <0.9A 240Vac: <0.45A

GP-3400T AGP3400-T1-D24(PFXGP3400TAD)

Resolution	640 X 480 pixels (VGA)
Dot pitch	W0.237 x H0.237 mm [W0.01 x H0.01 in.]
Effective Display Area	W153.7 X H115.8mm [W6.05 X H4.56in.]
Display Colors	65,536 Colors (No blink)/16,384 Colors (Blink)
Backlight	CCFL (User nonreplaceable parts, return system to distributor.)
Brightness Control	8 Levels (Adjusted with the touch panel)
Contrast Control	Not applicable
Backlight Service Life	54,000 hrs. or more (continuous operation at 25℃ before backlight brightness decreases to 50% or backlight starts to blink)
Language Fonts	Japanese: 6,962 (JIS Standards 1 & 2) (including 607 non-kanji characters), ANK: 158 (Korean fonts, Simplified Chinese and Traditional Chinese fonts are downloadable.
Character Sizes	Standard font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts, Stroke font: 6 to 127 pixel fonts, Image font: 8 to 72 pixel fonts
Font Sizes	Standard font: Width can be expanded up to 8 times., Height can be expanded up to 8 times.*1
8 x 16 dots	80 char. X 30 rows
16 x 16 dots	40 char. X 30 rows
32 x 32 dots	20 char. X 15 rows
8 x 8 dots	80 char. X 60 rows
Program Area	FLASH EPROM 132 KB
Number of Step	Equivalent to 15,000 steps *2
Variable Area	SRAM 64 KB (uses lithium battery)*3
Application Memory	FLASH EPROM 16 MB *4
Data Backup	SRAM 320KB (uses lithium battery)*5
Clock Accuracy	±65 sec./month (deviation at room temperature and power is OFF)*6
Touch Panel Type	Resistive Film (analog)
Touch Panel Resolution	1,024 X 1,024
Touch Panel Service Life	1,000,000 times or more
Serial (COM1)	RS-232C/422/485, Asynchronous Transmission, Data Length: 7 or 8 bit, Parity: none, Even or Odd, Stop Bit: 1 or 2 bit, Data Transmission Speed: 2,400 bps to 115.2 kbps, Connector: D-Sub9 (plug)
Serial (COM2)	RS-422/485, Asynchronous Transmission, Data Length: 7 or 8 bit, Parity: none, Even or Odd, Stop Bit: 1 or 2 bit, Data Transmission Speed: 2,400 bps to 115.2 kbps, 187.5kbps (MPI), Connector: D-Sub9 (socket)
Ethernet (LAN)	IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX, Connector: Modular jack (RJ-45)×1
Expansion Unit 1	Communication Expansion Unit x 1
USB (TYPE-A)	Conforms to USB1.1. (TYPE-A conn.) X 1, Power Supply Voltage: DC5V±5%, Output Current: 500mA (max.), Communication Distance: 5m (max.)
Expansion Memory	Function Expansion Memory x 1 (on internal circuit board)
CF Card	Compact Flash CF Card Slot (TYPE-II) X 1
Sound Output	Speaker Output, 70mW (Rated Load: 8Ω, Frequency: 1kHz), Connector: 2-piece terminal block (AUX) X 1
AUX Input/Output	Alarm Output, RUN Output, Buzzer Output, Rated Voltage: DC24V, Rated Current: 50mA, Remote Reset Input, Input Voltage: DC24V, Connector: 2-piece terminal block (AUX) X 1

1 Other font sizes can be set up with the Editor software.

2 Up to 60,000 steps can be converted in software. However, this reduces internal memory capacity (for screen data) by 1 MB.

3 A Lithium battery's lifetime is:
10 years when the battery's ambient temperature is 40 oC or less.
4.1 years when the battery's ambient temperature is 50 oC or less.
1.5 years when the battery's ambient temperature is 60 oC or less.
When used for back up: Approximately 100 days, with a fully charged battery.
Approximately 6 days, with a half-charged battery.

4 Capacity available for user application. 8 MB available if the revision of the unit is earlier than Rev. 4, or GP-Pro EX Ver. 2.5 or earlier is used.

5 A Lithium battery's lifetime is:
10 years when the battery's ambient temperature is 40 oC or less.
4.1 years when the battery's ambient temperature is 50 oC or less.
1.5 years when the battery's ambient temperature is 60 oC or less.
When used for back up: Approximately 100 days, with a fully charged battery.
Approximately 6 days, with a half-charged battery.

6 Depending on the operating temperature and age of unit, the clock can deviate from -380 to +90 sec./month. For systems where this level of deviation is a problem, the user should monitor and make adjustments when required.

General Specifications

International Safety Standards
Rated Input Voltage	DC 24V
Input Voltage Limits	DC 19.2 to 28.8V
Allowable Voltage Drop	10 ms (max.)
Power Consumption	28 W or less
In-Rush Current	30 A or less
Voltage Endurance	AC1,000V 20mA for 1 minute, (between charging and FG terminals)
Insulation Resistance	DC500V 10MΩ (min.), (between charging and FG terminals)
Surrounding Air Temperature	0 to 50 °C (32 to 122 °F)
Storage Temperature	-20 to 60 °C (-4 to 140 °F)
Ambient Humidity	10 to 90% RH (Wet bulb temperature: 39℃ max. - no condensation.)
Storage Humidity	10 to 90% RH (Wet bulb temperature: 39℃ max. - no condensation.)
Dust	0.1mg/m³ and below (non-conductive levels)
Pollution Degree	For use in Pollution Degree 2 environment
Atmosphere	Free of corrosive gases
Air Pressure (altitude range)	800 to 1,114 hPa (2,000 m [6,561ft.] above sea level or less)
Vibration Resistance	IEC/EN61131-2 compliant, 5 to 9Hz Single amplitude 3.5mm [0.14in.], 9 to 150Hz Fixed acceleration: 9.8m/s², X,Y,Z directions for 10 cycles (100 minutes)
Concussion Resistance	IEC/EN61131-2 compliant, 147 m/s², X, Y, Z directions for 3 times
Electrostatic Discharge Immunity	Contact Discarge Method: 6kV (IEC/EN61000-4-2 Level 3)
Grounding	Functional grounding: Grounding resistance of 100Ω, 2mm² or thicker wire, or your country's applicable standard. (Same for FG and SG terminals)
Structure	Equivalent to IP65f NEMA #250 TYPE 4X/13 (Front surface of embedded panel)*7
Installation Configuration	Embedded panel
Cooling Method	Natural air circulation
Weight Approx.	1.8kg [4.0lb] max. (unit only)
External Dimensions	W215 X H170 X D60mm , [W8.46 X H6.69 X D2.36in.]
Panel Cut Dimensions	W204.5 x H159.5 mm [W8.05 x H6.28 in.], Panel thickness area: 1.6 to 10 mm [0.06 to 0.39 in.]*8
