Pressure Sensors/Switches

Series: Pressure transducer P-7100

Pressure medium Corrosive gases/liquids compatible with SUS304, SUS316L
Pressure range 0~100kPa, -100~100kPa, 0~1MPa, 0~133.3kPa abs
Supply voltage 5±0.5V DC
Output 0.5~4.5V DC (ratio metric)
Pressure port R1/8, M5 female

Series: Pessure transducer P-8505

Pressure medium Corrosive gases/liquids compatible with SUS316L
Port Size Φ17.5 mm
Pressure Type Gauge
Pressure range 0~50 kPa,0~100 kPa,0~350 kPa,0~1000 kPa
Power 1.5mA Constant current
Output 90±30 mV

Series: Pressure transducer P-8305

Pressure medium Corrosive gases/liquids compatible with SUS316L
Port Size Φ27.1 mm
Pressure Type Gauge
Pressure range 0~10 kPa
Power 1.5mA Constant current
Output 25±10 mV

Series: Pressure transducer P-8300

Pressure medium Corrosive gases/liquids compatible with SUS316L
Port Size Φ19.8 mm
Pressure Type Gauge / Absolute
Pressure range 0~49.0 kPa,0~98.1 kPa,0~343 kPa,0~981 kPa,0~34.3 kPa (abs),0~98.1 kPa (abs)
Power 1.5mA Constant current
Output 100 ±50 mV

Series: Pressure transducer P-3000S

Pressure medium Non-corrosive gases
Port Size Φ3.5mm Tube
Pressure Type Gauge / Differential / Absolute
Pressure range 0~4.9 kPa,0~9.81 kPa,0~49.0 kPa,0~98.1 kPa,0~490 kPa,0~686 kPa,±9.81 kPaD,±49.0 kPaD,±98.1 kPaD,0~34.3 kPa (abs),0~98.1 kPa (abs)
Power 1.5mA Constant current
Output 70±30 mV,50±20 mV,100±30 mV,50±20 mV,80±40 mV

Series: Pressure transducer P-2000

Pressure medium Non-corrosive gases
Port Size Φ3.2mm Tube
Pressure Type Gauge
Pressure range 0~9.81, 0~49.0, 0~98.1, 0~343,0~490, 0~686, 0~981 kPa
Power 1.5mA Constant current
Output 90±30 mV

Series: Pressure transducer with amp. PA-840

Pressure medium Gas and liquid which does not corrode SUS316L
Gas and liquid which does not corrode O-ring (Fluoro rubber) G2 Fitting
Pressure Type Gauge/Absolute
Pressure range -0.1~0.1 MPa,-0.1~0.35 MPa,0~1.0 MPa,0~3.5 MP
Supply voltage 21.6~26.4 V DC (リップル含む)
Output 1 ~ 5 V
Pressure port R 1/4, G 1/4
Protection grade IP67

Series: Pressure transducer with amp. PA-848

Pressure medium Gas and liquid which does not corrode SUS316L
Gas and liquid which does not corrode O-ring (Fluoro rubber) G2 Fitting
Pressure Type Gauge/Absolute
Pressure range -0.1~0.1 MPa,-0.1~0.35 MPa,0~1.0 MPa,0~3.5 MP
Supply voltage 21.6~26.4 V DC (リップル含む)
Output 4~20 mA DC
Pressure port R 1/4, G 1/4
Protection grade IP67

Series: Pressure transducer with amp. PA-968

Pressure medium Gases/Liquids compatible with 17-4PH
Pressure Type Gauge
Pressure range 0 ~ 5MPa,0 ~ 10MPa,0 ~ 20MPa,0 ~ 35MPa,0 ~ 50MPa
Supply voltage 10.8 ~ 30 VDC
Output 4 ~ 20 mA
Pressure port R1/4, G3/8

Series: Pressure transducer with amp. PA-870

Pressure medium Corrosive gases/liquids compatible with SUS316 and Hastelloy C-22
Pressure Type Gauge
Pressure range 0 ~ 2MPa,0 ~ 3.5MPa,0 ~ 5MPa
Supply voltage 12 ~ 24 VDC
Output 1 ~ 5 VDC
Pressure port R 1/4

Series: Pressure transducer with amp. PA-860

Pressure medium Hydraulic oil
Pressure Type Gauge
Pressure range 0 ~ 5MPa,0 ~ 10MPa,0 ~ 20MPa,0 ~ 35MPa
Supply voltage 12 ~ 24 VDC
Output 1 ~ 5 VDC
Pressure port R 1/4,G 3/8

Series: Pressure transducer with amp. PA-838

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure Type Gauge
Pressure range 0 ~ 49.0 kPa,0 ~ 98.1 kPa,0 ~ 981 kPa
Supply voltage 24 VDC
Output 4 ~ 20 mA
Pressure port G 1/8,R 1/4,1/4 VCR

Series: Pressure transducer with amp. PA-830

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure Type Gauge / Absolute
Pressure range 0 ~ 9.8 kPa,0 ~ 49.0 kPa,0 ~ 98.1 kPa,0 ~ 343 kPa,0 ~ 981 kPa,−100 ~ 0 kPa,0 ~ 34.3 kPa (abs),0 ~ 98.1 kPa (abs)
Supply voltage 12 ~ 24 VDC
Output 1 ~ 5 VDC
Pressure port G 1/8,R 1/4,1/4 VCR

Series: Pressure transducer with amp. PA-100

Pressure medium Non-corrosive gases
Pressure Type Differential
Pressure range 0 ~ 1 kPa,0 ~ 2 kPa,0 ~ 5 kPa,± 1 kPa,± 2 kPa,±5 kPa
Supply voltage 5 VDC
Output 0.5 ~ 4.5 VDC
Pressure port Φ2.5 mm

Series: Pressure transducer with amp. PA-20

Pressure medium Non-corrosive gases
Pressure Type Gauge
Pressure range -100~0kPa, -100~300 kPa
Supply voltage 10.8 ~ 30 VDC
Output 1 ~ 5 VDC
Pressure port 2-M5 female/M5 male

Series: Pressure transducer with amp. PA-960

Pressure medium Gases/Liquids compatible with 17-4PH
Pressure Type Gauge
Pressure range 0 ~ 5MPa,0 ~ 10MPa,0 ~ 20MPa,0 ~ 35MPa,0 ~ 50MPa
Supply voltage 10.8 ~ 30 VDC
Output 1 ~ 5 VDC
Pressure port R1/4, G3/8

Series: Pressure transducer with amp. PA-838-D

Pressure medium Corrosive gases/liquids compatible with SUS304
Pressure Type Differential
Pressure range 0 ~ 10 kPaD,0 ~ 50 kPaD,0 ~ 100 kPaD
Supply voltage 24 VDC
Output 4 ~ 20 mA
Pressure port Flare fitting(7/16-20UNF)

Series: Pressure transducer with amp. PA-800

Pressure medium Corrosive gases/liquids compatible with SUS316L or SUS316
Pressure Type Gauge
Pressure range 0 ~ 98.1 kPa,0 ~ 343 kPa,0 ~ 981 kPa,−98.1 ~ 0 kPa
Supply voltage 12 ~ 24 VDC
Output 1 ~ 5 VDC
Pressure port G 3/8

Series: Pressure transducer with amp. PA-758

Pressure medium Corrosive gases/liquids compatible with SUS304, SUS316L
Pressure Type Gauge / Absolute
Pressure range 0 ~ 100 kPa,0 ~ 350 kPa,0 ~ 1.0 MPa,0 ~ 3.5 MPa,−100 ~ 0 kPa,−100 ~ 100 kPa,−100 ~ 300 kPa,0 ~ 100 kPa(abs)
Supply voltage 24 VDC
Output 4 ~ 20mA
Pressure port R1/8,R1/4

Series: Pressure transducer with amp. PA-750

Pressure medium Corrosive gases/liquids compatible with SUS304, SUS316L
Pressure Type Gauge / Absolute
Pressure range 0 ~ 100 kPa,0 ~ 350 kPa,0 ~ 1.0 MPa,0 ~ 3.5 MPa,−100 ~ 0 kPa,−100 ~ 100 kPa,−100 ~ 300 kPa,0 ~ 100 kPa(abs)
Supply voltage 10.8 ~30 VDC
Output 1 ~ 5 VDC
Pressure port R1/8,R1/4

Series: Pressure transducer with amp. PA-708

Pressure medium Corrosive gases/liquids compatible with Fluorocarbon polymer.
Pressure Type Gauge (Compound)
Pressure range −100 ~ 100 kPa,−100 ~ 300 kPa,−100 ~ 600 kPa
Supply voltage 24 VDC
Output 4 ~ 20 mA
Pressure port Φ1/2" × 3/8"

Series: Pressure transducer with amp. PA-500

Pressure medium Non-corrosive gases / liquids
Pressure Type Gauge
Pressure range 0 ~ 9.81 kPa,0 ~49 kPa,0 ~ 98.1 kPa,0 ~ 343 kPa,0 ~ 490 kPa,0 ~ 981kPa,−100 ~ 0 kPa
Supply voltage 12 ~ 24 VDC
Output 1 ~ 5 VDC
Pressure port R 1/4,G 1/4

Series: Pressure transducer with amp. PA-930-A

Pressure medium Corrosive gases/liquids compatible with SUS316L and nickel alloy
Pressure Type Absolute
Pressure range 0 ~ 100 kPa (abs),0 ~ 200 kPa (abs)
Supply voltage 12 ~ 24 VDC
Output 1 ~ 5 VDC
Pressure port 9/16-18UNF

Series: Pressure transducer with amp. PA-878

Pressure medium Corrosive gases/liquids compatible with SUS316 and Hastelloy C-22
Pressure Type Gauge
Pressure range 0 ~ 2MPa,0 ~ 3.5MPa,0 ~ 5MPa
Supply voltage 12 ~ 24 VDC
Output 4 ~ 20 mA
Pressure port R 1/4

Series: Pressure transducer with amp. PA-868

Pressure medium Hydraulic oil
Pressure Type Gauge
Pressure range 0 ~ 5MPa,0 ~ 10MPa,0 ~ 20MPa,0 ~ 35MPa
Supply voltage 12 ~ 24 VDC
Output 4 ~ 20 mA
Pressure port R 1/4,G 3/8

Series: Pressure transducer with amp. PA-858

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure Type Gauge / Absolute
Pressure range 0 ~ 100 kPa,0 ~ 350 kPa,0 ~ 1000 kPa,−100 ~ 0 kPa,−100 ~ 300 kPa,0 ~ 100 kPa (abs)
Supply voltage 24 VDC
Output 4 ~ 20 mA
Pressure port R 1/4,G 3/8,G 1/4

Series: Pressure transducer with amp. PA-850

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure Type Gauge / Absolute
Pressure range 0 ~ 100 kPa,0 ~ 350 kPa,0 ~ 1000 kPa,−100 ~ 0 kPa,−100 ~ 100 kPa,−100 ~ 300 kPa,0 ~ 100 kPa (abs)
Supply voltage 12 ~ 24 VDC
Output NPN/PNP open collector output 1 and 1 ~ 5 VDC
Pressure port R 1/4,G 3/8,G 1/4

Series: Pressure switch PS40

Pressure medium Non-corrosive gases
Pressure reference Gauge
Pressure range -100~0kPa, 0~50 kPa,0 ~ 100 kPa,0 ~ 1000 kPa
Power 10.8 ~ 30 VDC
Output NPN/PNP open collector output and 1 ~ 5 VDC, or output 2
Pressure port R1/8 male,M5 female

Series: Pressure switch PS30

Pressure medium Non-corrosive gases
Pressure reference Gauge
Pressure range -100~100kPa, -100~1000 kPa
Power 12 ~ 24 VDC
Output NPN/PNP open collector output 2
Pressure port M5 female

Series: Pressure switch PS91

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure reference Gauge
Pressure range -100 ~ 10 kPa
Power 12 ~ 24 VDC
Output NPN/PNP open collector output 2
Pressure port Gasket joint 9/16-18UNF

Series: Pressure switch PS87

Pressure medium Corrosive gases/liquids compatible with SUS316 and Hastelloy C-22
Pressure reference Gauge
Pressure range 0 ~ 3.5MPa,0 ~ 5MPa
Power 12 ~ 24 VDC
Output Open collector output insulated by a photocoupler output 1
Pressure port R 1/4

Series: Pressure switch PS86

Pressure medium Hydraulic oil
Pressure reference Gauge
Pressure range 0 ~ 5MPa,0 ~ 10MPa,0 ~ 20MPa,0 ~ 35MPa
Power 12 ~ 24 VDC
Output Open collector output insulated by a photocoupler output 1
Pressure port R 1/4,G 3/8

Series: Pressure switch PS85

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure reference Gauge / Absolute
Pressure range -100 ~ 100 kPa,-100 ~ 350 kPa,-100 ~ 1000 kPa,0 ~ 100 kPa (abs)
Power 10.8 ~ 30 VDC
Output NPN/PNP open collector output 2
Pressure port R 1/4,G 3/8,G 1/4

Series: Pressure switch PS83

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure reference Gauge / Absolute
Pressure range 0 ~ 49.0 kPa,0 ~ 98.1 kPa,0 ~ 343 kPa,0 ~ 981 kPa,-98.1 ~ 0 kPa,0 ~ 34.3 kPa (abs),0 ~ 98.1 kPa (abs)
Power 12 ~ 24 VDC
Output NPN open collector output 2
Pressure port G 1/8,R 1/4,1/4 VCR

Series: Pressure switch PS8

Pressure medium Corrosive gases/liquids compatible with SUS316L or SUS316
Pressure reference Gauge
Pressure range 0 ~ 98.1 kPa,0 ~ 343 kPa,0 ~ 981 kPa,-98.1 ~ 0 kPa
Power 12 ~ 24 VDC
Output NPN open collector output 2
Pressure port G 3/8

Series: Pressure switch PS60

Pressure medium Non-corrosive gases
Pressure reference Gauge
Pressure range -100~100kPa, -100~300kPa,-100 ~ 1000 kPa
Power 12 ~ 24 VDC
Output NPN/PNP open collector output 2
Pressure port M5 female

Series: Pressure switch PS6

Pressure medium Non-corrosive gases
Pressure reference Gauge
Pressure range -100~0kPa, 0 ~ 100 kPa,0 ~ 1000 kPa
Power 12 ~ 24 VDC
Output NPN/PNP open collector output and 1 ~ 5 VDC, or output 2
Pressure port R1/8 male,M5 female

Series: Pressure switch PS20

Pressure medium Non-corrosive gases
Pressure reference Gauge
Pressure range -100~0, -100~300 kPa
Power 10.8~30 V DC
Output NPN/PNP open collector output 1
Pressure port 2-M5 female screw,M5 male screw

Series: Pressure gauge PG-208

Pressure medium Corrosive gases/liquids compatible with SUS316L or SUS316
Pressure reference Gauge
Pressure range 0 ~ 100 kPa,0 ~ 1000 kPa,-100 ~ 0 kPa
Power Lithium battery 3.6 VDC/5 ~ 10 VDC or 10 ~ 24 VDC
Output NPN open collector output 2 and 0 ~ 1 VDC
Pressure port G 3/8

Series: Pressure gauge PG-200

Pressure medium Non-corrosive gases
Pressure reference Gauge / Absolute
Pressure range 0 ~ 10 kPa,0 ~ 100 kPa,0 ~ 1000 kPa,-100 ~ 0 kPa,0 ~ 100 kPa (abs)
Power Lithium battery 3.6 VDC/5 ~ 10 VDC or 10 ~ 24 VDC
Output NPN open collector output 2 and 0 ~ 1 VDC
Pressure port R 1/4,M5 female

Series: Pressure gauge PG-35L

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure reference Gauge
Pressure range -100 ~ 100 kPa,-100 ~ 1000 kPa
Power 10.8 ~ 30 VDC
Output NPN/PNP open collector output 2 and 1 ~ 5 VDC
Pressure port R 1/4,G 1/4,9/16-18UNF

Series: Pressure gauge PG-35H

Pressure medium Corrosive gases/liquids compatible with SUS316L
Pressure reference Gauge
Pressure range -0.1 ~ 10 MPa,-0.1 ~ 35 MPa
Power 10.8 ~ 30 VDC
Output NPN/PNP open collector output 2 and 1 ~ 5 VDC
Pressure port R 1/4,G 3/8

Series: Pressure gauge PG-35

Pressure medium Non-corrosive gases / liquids
Pressure reference Gauge / Absolute
Pressure range -100 ~ 100 kPa,-100 ~ 1000 kPa,0 ~ 100 kPa (abs)
Power 10.8 ~ 30 VDC
Output NPN/PNP open collector output 2 and 1 ~ 5 VDC
Pressure port R 1/4,G 3/8,G 1/4,9/16-18UNF

Series: Pressure gauge PG-30

Pressure medium Non-corrosive gases
Pressure reference Gauge
Pressure range -10 ~ 10 kPa,-100 ~ 100 kPa,-100 ~ 1000 kPa
Power 10.8 ~ 30 VDC
Output NPN/PNP open collector output 2 and 1 ~ 5 VDC
Pressure port 2-RC 1/8

Series: Pressure gauge PG-20

Pressure medium Gases and Liquids compatible with SUS316L
Pressure reference Gauge / Compound
Pressure range 0 ~ 0.5 MPa,0 ~ 1.0 MPa,-0.1 ~ 0.5 MPa,-0.1 ~ 1.0 MPa
Power 12 ~ 24 VDC
Output NPN/PNP open collector output 2, or output 1 and 1 ~ 5 VDC / 4~ 20 mA
Pressure port 1.5 inch W seal,1.125 inch W seal

Series: Pressure gauge PG-75

Pressure medium Crosive gases and Liquids compatible with SUS304 or SUS316L
Pressure reference Gauge (Compound)
Pressure range 0 ~ 100 kPa,0 ~ 1.0 MPa,0 ~ 3.5 MPa,-100~100kPa, -0.1 ~ 1.0 MPa,-0.1 ~ 3.5 MPa
Power 10.8 ~ 30 VDC
Output NPN/PNP open collector output 2 and 1 ~ 5 VDC / 4~ 20 mA
Pressure port R 1/8,R 1/4

Series: Handheld digital manometer PG-100

Pressure medium Non-corrosive gases
Pressure reference Gauge / Absolute
Pressure range 0~10kPa, 0~100kPa, 0~1000kPa, -100~0 kPa,-10~10kPa, -100~100kPa, -100~1000 kPa,0~100 kPa(abs)
Power Lithium battery 3.6 VDC
Output 3 1/2 digit LCD display
Pressure port M5 female

Series: Handheld digital manometer PG-100N

Pressure medium Non-corrosive gases
Pressure reference Gauge (Compound)
Pressure range -10~10kPa, -100~100 kPa, -100~1000 kPa
Power AAA dry battery DC 1.5 V × 2
Output 3 1/2 digit LCD display
Pressure port M5 female

Series: Handheld digital manometer PG-100B

Pressure medium Gases / liquids compatible with SUS316L
Pressure reference Gauge/Absolute
Pressure range -100~100, -100~1000 kPa, 0~100 kPa abs
Power AAA dry battery DC 1.5 V × 2
Output 3 1/2 digit LCD display
Pressure port M5 female

Series: Pressure indicator PZ-200

Input signal 1~5 V (V) / 4~20 mA (I)
Input impedance Approx. 120 kΩ (V) / 51 Ω (I)
Supply voltage 12~24 V DC
Output status NPN 4-point Open collector output
Analog output 4~20 mA (Current output)
Display accuracy ± 0.1 (±2 counts)

Series: Pressure indicator PZ-30

Input signal 1~5 V (V) / 4~20 mA (I)
Input impedance 10 kΩ (V) /250 Ω (I)
Supply voltage 10.8~30 V DC
Output status NPN/PNP 2-point open collector output
Analog output 1~5 VDC (Voltage output) / 4~20 mA (Current output)
Display accuracy ± 0.2 (±1 counts)

Series: Pressure transducer with amp. PA-204

Pressure medium Gases(No corro sive)

Pressure Type

Gauge(Positive)
Pressure range 0~5kPa, 0~10kPa, 0~50kPa, 0~100kPa
Supply voltage 5V±0.5V
Output 0.5~4.5V
Pressure por t φ3.2
Dimensions、 Net weight 19×15×15mm、約1.8g

Series: Notes to Pressure Sensors/Switches

  Click on the following, you can download the PDF.
Note.1 Outline
Note.2 Operating Principles
Note.3 Applications
Note.4 Handling notes
Note.5 Glossary
Note.6 Pressure Sensors Recommended External Circuit
Note.7 Pressure Switches Typical Circuit Connection



Product and Technology News

Liquid leak sensors

Download Catalogue
