How does it work?


You can communicate any device that has an RS232 or RS485 serial port, to a TCP / IP network, through its two communication ports, either Wi-Fi wireless or wired Ehernet. Now you can connect two devices linked with RS232/RS485 through an Ethernet network. Moreover, you will be able to gain access to these devices from a computer.

  •
  •
  •  1 Wi-Fi port with its antenna inside the device
  •  1 Ethernet port 10/100 Base T
  •  1 Serial port (RS232 or RS485)
  •  DIN rail mouting
  •  Easy web-based password-protected configuration
  •  Statistics and monitoring by web
  •  Automatic link recovery after communication failures
  •  SNMP Traps
  •  Wide range power supply: +10 to +30Vdc


You can communicate any device that has an RS232 or RS485 serial port, to a TCP / IP network, through its two communication ports, either Wi-Fi wireless or wired Ehernet. Now you can connect two devices linked with RS232/RS485 through an Ethernet network. Moreover, you will be able to gain access to these devices from a computer.

  •
  •
  •  Direct connection with Virtual COM Port
  •  Point to Point TCP tunnel
  •  Point to Point UDP tunnel
  •  Point to Multi Point UDP tunnel
  •  Multi Point UDP tunnel


You can communicate any device that has an RS232 or RS485 serial port, to a TCP / IP network, through its two communication ports, either Wi-Fi wireless or wired Ehernet. Now you can connect two devices linked with RS232/RS485 through an Ethernet network. Moreover, you will be able to gain access to these devices from a computer.

  •
  •
  •  PLC & SCADA systems
  •  Industrial Automation
  •  Remote monitoring systems
  •  Access control systems


You can communicate any device that has an RS232 or RS485 serial port, to a TCP / IP network, through its two communication ports, either Wi-Fi wireless or wired Ehernet. Now you can connect two devices linked with RS232/RS485 through an Ethernet network. Moreover, you will be able to gain access to these devices from a computer.

  •
  • PART NUMBER DESCRIPTION
    SSE232-1B0-00-LE-WiFi 1 port configurable RS-232 or RS-485.
