Belt Sway Switch KP-880


Switches to detect tilt and meandering of conveyor belt.

Features
  • • Light weight/robust structure as the housing is made of aluminum casting.
  • • IP 67, outdoor drip-proof structure.
  • • Two-contact system for both alarm and control.
  • • Tilt angle 70 degrees Max.

Operating Principles


This switch detects the belt gathering to one side or meandering to avoid the conveyor belt from breaking and any mechanical problem.

Model KP-880
Action Auto Recovery
Indication No
（over 0.03 as option）
Power Source No
Output Contact SPDT x 2
Contact Capacity AC250V 15A, DC30V 6A
Pressure 980kPa
Operating Angle 20°and 35°, changeable
Process Connection 2-φ10, pitch 110
Enclosure Rating IP67
Roller Material standard SGP, option PVC or SUS304
Weight 3.5kg
