Specifications

GPH6000 Series Lineup / Specifications

	GPH-6500WC	GPH-6400WC
Model No.	PFXGPH6500WCD	PFXGPH6400WAD
Details	Spec	Spec
Display	10” Wide (800 x 1,280)	7.0” Wide (1024 x 600)
Display Colors	16M colors
Backlight	White LED 16 level brightness control
Touch Panel	Projected capacitive(Multi-touch) Touch panel service life = 50,000 hours	Projected capacitive(Multi-touch) Touch panel service life = 30,000 hours
Function SW	OP, F1 to F17	OP, F1 to F13
Navigator	↑, ↓, ←, →
Interface	COM: RS-232C/422/485 x1 Ethernet : 10BASE-T / 100BASE-TX x1 USB: host type A x1 SDCard Slot: Storage x1 Emergency Stop switch x1 Enabling switch x1 Key switch x1
Memory(GP-Pro EX)	Application memory : Media : eMMC Flash / Screen area: 64MB / User font area 8 MB / Logic program area: 132KB Backup memory : Screen Area: FRAM 320KB, Variable Area: FRAM 64KB, Battery : Replaceable battery / Primary battery for clock data backup
Power (Input voltage)	DC24V (19.2 to 28.8Vdc)
Operating Temp/ Humidity	-20-60 °C / 5% to 85%(no condensation)
Storage Temp	-20-70 °C / 5% to 85%(no condensation)
Certifications	IP65F, Type 1, Type 4X (indoor use only), Type 13 (on the front panel when properly installed in an enclosure), CE, UL and cUL, RMC, KC, EAC, RoHS, WEEE
